| Print Method | Continuous system (charged control) |
| Operation Screen | 5.7" color LCD / touch panel |
| Print Height | 1–10 mm (50μm nozzle) |
| Max Printing Speed | 2660 characters/second (5×5 dot font, spacing 1) |
| Printing Lines & Dot Matrix | 1–5 lines: 5×5<br>1–4 lines: 5×5, 5×N<br>1–3 lines: 7×8, 7×5, 7×N<br>1–2 lines: 12×10, 10×8, 9×9, 9×7<br>1 line: 24×24, 24×18, 16×16, 16×12 |
| Message Storage Capacity | Up to 999 messages |
| Character Types | Alphabet (upper/lower case), numbers, symbols, Hiragana, Katakana, Kanji (JIS 1 & 2), Simplified Chinese (GB2312), user-defined characters |
| Date & Time Print Function | Gregorian year, Japanese era, date, weekday, time (12/24h), Julian date, week number, month phase, AM/PM, shift code, character assignment |
| Numbering Function | Up to 10 digits, initial value setting, up/down count, carry (1–9999), zero suppression, character assignment, base setting (binary to base 36), separable format |
| Distance Printing Function | Up to 10 digits, separable format |
| Barcode Printing | ITF, NW7JAN, Code39, Code128 |
| 2D Code Printing | DataMatrix, QR Code |
| External Device Connection | Signal lamp, RS-232C, encoder, USB flash drive, UPS |
| Data Entry | Touch panel, RS-232C communications |
| Dimensions (W × D × H) | Main body: 400 × 280 × 532 mm (excluding protrusions)<br>Printhead: Φ49.2 × 197 mm |
| Operating Environment | Temperature: 0–40°C<br>Humidity: 10–85% RH (non-condensing) |
| Power Source | AC 90–264V, 47–63Hz, 80W |
| Weight | 22 kg |
| Grounding | Class D |
